Scatter Gather in Mule 4

Published on

May 7, 2021

Author

MuleSoft Integration Team

Scatter Gather Pattern helps MuleSoft developers distribute different tasks to achieve parallel processing of tasks/messages/events & then finally aggregate the responses as a single response.

Scatter Gather Component

The Scatter-Gather component receives a Mule event and sends a reference of this Mule event to each processing route.
Each of the processing routes starts executing in parallel then returns a Mule event. This is because the Scatter-Gather component executes each route in parallel, not sequentially.
After all processing routes have finished execution, the Scatter-Gather component creates a new Mule event that combines all resulting Mule events from each route. It then passes the new Mule event to the next component in the flow.

Scatter Gather Example:

In Scatter-Gather flow, we have three routes: Flow Reference Component(Flow Reference routes the Mule event to another flow or sub-flow). One set Payload Transformer(The Set Payload component lets you update the payload of the message).

Scatter-Gather Flow

Both sub-flow contains a Database select query operation which gives us data from the Database. This transform message component converts the data from the Database into JSON format and a logger which will track the logs.

1) Route 1 contains a Flow reference of a sub-flow (db-flow1)

Flow refrence (db-flow1)

Configuration of select query operation –

Configuration XML:

<sub-flow name="db-flow1" doc:id="bf4acf02-bd0d-4156-9980-6aad5b1e908b" >
		<db:select doc:name="Select" doc:id="38eff10a-1141-4b16-aeb4-c3ed78eeae66" config-ref="Database_Config1">
			<db:sql ><![CDATA[select * from product]]></db:sql>
		</db:select>
		<ee:transform doc:name="Transform Message" doc:id="d3590e43-a0c1-42e9-b6d5-562db1bec17d" >
			<ee:message >
				<ee:set-payload ><![CDATA[%dw 2.0
output application/json
---
payload]]></ee:set-payload>
			</ee:message>
		</ee:transform>
		<logger level="INFO" doc:name="Logger" doc:id="342df3a5-b836-4a4c-a775-06bde82712d4" message="#[payload]"/>
	</sub-flow>

2) Route 2 contains a Flow reference of a sub flow (db-flow2)

Flow refrence (db-flow2)

Configuration of Select Query :

Configuration of select query for db-flow2

Configuration XML:

<sub-flow name="db-flow2" doc:id="f88987da-ea4c-44f5-bc39-0096d78eaa72" >
		<db:select doc:name="Select" doc:id="930efe51-8e73-40f2-9184-8174be3e9d01" config-ref="Database_Config1">
			<db:sql ><![CDATA[select * from product1]]></db:sql>
		</db:select>
		<ee:transform doc:name="Transform Message" doc:id="ec45dbb2-92eb-43e2-836b-84029b0f4290" >
			<ee:message >
				<ee:set-payload ><![CDATA[%dw 2.0
output application/json
---
payload]]></ee:set-payload>
			</ee:message>
		</ee:transform>
		<logger level="INFO" doc:name="Logger" doc:id="b100cf5e-809e-4d09-bfba-05f8114b748d" message="#[payload]"/>
	</sub-flow>

3) Route 3 contains a Set Payload component

Route 3 (Set Payload)

Configuration of Set Payload:

Configuration of Set Payload

Configuration XML:

<route >
				<set-payload value="scatter-gather flow payload" doc:name="Set Payload" doc:id="f8c0d364-044e-4e59-b31d-3fb4e8805466" />
				<logger level="INFO" doc:name="Logger" doc:id="62563f04-a79c-4cef-9ab9-5eea9e17637a" message="#[payload]"/>
			</route>

Tables in Database:

Product Table

2. Product1 Table

Product1 Table

Flow XML:

<?xml version="1.0" encoding="UTF-8"?>

<mule xmlns:ee="http://www.mulesoft.org/schema/mule/ee/core" xmlns:db="http://www.mulesoft.org/schema/mule/db"
	xmlns:http="http://www.mulesoft.org/schema/mule/http"
	xmlns="http://www.mulesoft.org/schema/mule/core" xmlns:doc="http://www.mulesoft.org/schema/mule/documentation" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd
http://www.mulesoft.org/schema/mule/http http://www.mulesoft.org/schema/mule/http/current/mule-http.xsd
http://www.mulesoft.org/schema/mule/db http://www.mulesoft.org/schema/mule/db/current/mule-db.xsd
http://www.mulesoft.org/schema/mule/ee/core http://www.mulesoft.org/schema/mule/ee/core/current/mule-ee.xsd">
	<http:listener-config name="HTTP_Listener_config" doc:name="HTTP Listener config" doc:id="dc87c934-3f63-4e54-a7a6-57b9852c6e2a" >
		<http:listener-connection host="0.0.0.0" port="8081" />
	</http:listener-config>
	<db:config name="Database_Config1" doc:name="Database Config" doc:id="99af9304-0aa1-484d-986c-be9022aa3d21" >
		<db:my-sql-connection host="localhost" port="3306" user="root" password="Caelius@123" database="muletrainingdb" />
	</db:config>
	<flow name="scatter-gather" doc:id="b7ea3fed-f402-4359-8a0d-c7a952903010" >
		<http:listener doc:name="Listener" doc:id="8e71879a-1711-4c3d-b4a1-1effa23cdec0" config-ref="HTTP_Listener_config" path="/test"/>
		<scatter-gather doc:name="Scatter-Gather" doc:id="f79ea679-6ffc-432c-a8e5-c56c9a6ff025" >
			<route >
				<flow-ref doc:name="db-flow1" doc:id="da378a2d-6584-4682-be11-746cb1b443a6" name="db-flow1"/>
			</route>
			<route >
				<flow-ref doc:name="db-flow2" doc:id="765de27e-c4ac-4c0b-bced-58f49f2bc460" name="db-flow2"/>
			</route>
			<route >
				<set-payload value="scatter-gather flow payload" doc:name="Set Payload" doc:id="f8c0d364-044e-4e59-b31d-3fb4e8805466" />
				<logger level="INFO" doc:name="Logger" doc:id="62563f04-a79c-4cef-9ab9-5eea9e17637a" message="#[payload]"/>
			</route>
		</scatter-gather>
		<ee:transform doc:name="Transform Message" doc:id="df9303a4-c1dd-4eec-a731-a9358859ed18">
					<ee:message>
						<ee:set-payload><![CDATA[%dw 2.0
output application/json
---
payload]]></ee:set-payload>
					</ee:message>
				</ee:transform>
	</flow>
	<sub-flow name="db-flow1" doc:id="bf4acf02-bd0d-4156-9980-6aad5b1e908b" >
		<db:select doc:name="Select" doc:id="38eff10a-1141-4b16-aeb4-c3ed78eeae66" config-ref="Database_Config1">
			<db:sql ><![CDATA[select * from product]]></db:sql>
		</db:select>
		<ee:transform doc:name="Transform Message" doc:id="d3590e43-a0c1-42e9-b6d5-562db1bec17d" >
			<ee:message >
				<ee:set-payload ><![CDATA[%dw 2.0
output application/json
---
payload]]></ee:set-payload>
			</ee:message>
		</ee:transform>
		<logger level="INFO" doc:name="Logger" doc:id="342df3a5-b836-4a4c-a775-06bde82712d4" message="#[payload]"/>
	</sub-flow>
	<sub-flow name="db-flow2" doc:id="f88987da-ea4c-44f5-bc39-0096d78eaa72" >
		<db:select doc:name="Select" doc:id="930efe51-8e73-40f2-9184-8174be3e9d01" config-ref="Database_Config1">
			<db:sql ><![CDATA[select * from product1]]></db:sql>
		</db:select>
		<ee:transform doc:name="Transform Message" doc:id="ec45dbb2-92eb-43e2-836b-84029b0f4290" >
			<ee:message >
				<ee:set-payload ><![CDATA[%dw 2.0
output application/json
---
payload]]></ee:set-payload>
			</ee:message>
		</ee:transform>
		<logger level="INFO" doc:name="Logger" doc:id="b100cf5e-809e-4d09-bfba-05f8114b748d" message="#[payload]"/>
	</sub-flow>
</mule>

Output Combining all routes:

  {
    "0": {
        "inboundAttachmentNames": [],
        "exceptionPayload": null,
        "inboundPropertyNames": [],
        "outboundAttachmentNames": [],
        "payload": [
            {
                "original_price": 1000.0,
                "product_id": 1,
                "name": "Hp Pavilion laptop",
                "offer_valid_until": "2016-06-27T10:45:56",
                "description": "Hp Laptop ",
                "brand_name": "HP",
                "offer_price": 1000.0
            },
            {
                "original_price": 3000.0,
                "product_id": 2,
                "name": "Macbook Pro laptop",
                "offer_valid_until": "2016-06-27T10:45:57",
                "description": "Apple Laptop ",
                "brand_name": "Apple",
                "offer_price": 3000.0
            },
            {
                "original_price": 2000.0,
                "product_id": 3,
                "name": "Mac Book  laptop",
                "offer_valid_until": "2016-06-27T10:45:57",
                "description": "Apple Laptop ",
                "brand_name": "Apple",
                "offer_price": 2000.0
            },
            {
                "original_price": 4000.0,
                "product_id": 4,
                "name": "IBM laptop",
                "offer_valid_until": "2016-06-27T10:45:57",
                "description": "IBM Laptop ",
                "brand_name": "IBM",
                "offer_price": 4000.0
            },
            {
                "original_price": 1000.0,
                "product_id": 5,
                "name": "MotoX Mobile",
                "offer_valid_until": "2016-06-27T10:45:57",
                "description": "Motorola Mobile ",
                "brand_name": "Motorola",
                "offer_price": 1000.0
            },
            {
                "original_price": 5000.0,
                "product_id": 6,
                "name": "Samsung Note 5",
                "offer_valid_until": "2016-06-27T10:45:57",
                "description": "Samsung Mobile ",
                "brand_name": "Samsung",
                "offer_price": 5000.0
            }
        ],
        "outboundPropertyNames": [],
        "attributes": null
    },
    "1": {
        "inboundAttachmentNames": [],
        "exceptionPayload": null,
        "inboundPropertyNames": [],
        "outboundAttachmentNames": [],
        "payload": [
            {
                "Name": "hp",
                "id": 1001
            },
            {
                "Name": "asus",
                "id": 1002
            },
            {
                "Name": "dell",
                "id": 1003
            },
            {
                "Name": "apple",
                "id": 1004
            }
        ],
        "outboundPropertyNames": [],
        "attributes": null
    },
    "2": {
        "inboundAttachmentNames": [],
        "exceptionPayload": null,
        "inboundPropertyNames": [],
        "outboundAttachmentNames": [],
        "payload": "scatter-gather flow payload",
        "outboundPropertyNames": [],
        "attributes": {
            "headers": {
                "user-agent": "PostmanRuntime/7.28.0",
                "accept": "*/*",
                "postman-token": "01f2bd2d-5eaa-4d9f-bd6a-164ab590be81",
                "host": "localhost:8081",
                "accept-encoding": "gzip, deflate, br",
                "connection": "keep-alive"
            },
            "clientCertificate": null,
            "method": "GET",
            "scheme": "http",
            "queryParams": {},
            "requestUri": "/test",
            "queryString": "",
            "version": "HTTP/1.1",
            "maskedRequestPath": null,
            "listenerPath": "/test",
            "localAddress": "/127.0.0.1:8081",
            "relativePath": "/test",
            "uriParams": {},
            "rawRequestUri": "/test",
            "rawRequestPath": "/test",
            "remoteAddress": "/127.0.0.1:54523",
            "requestPath": "/test"
        }
    }
}

All the MuleSoft Anypoint platform users can use this guide to implement scatter-gather pattern in their Mule projects.

Find more MuleSoft technical guides at Caelius Consulting Resource Centre.
